FA370 Digital AC/DC Clamp Meter | Accurate Handheld Multimeter

Model Number: FA370
Dimensions: 250 × 99 × 43 mm
Weight: 0.48 kg
DC Voltage Range: 0.4V / 4V / 40V / 400V
AC Voltage Range: 4V / 40V / 400V / 750V
DC Current Range: 400A / 1000A
AC Current Range: 400A / 1000A
Frequency Range: 40Hz / 400Hz / 4kHz / 40kHz / 100kHz
Resistance Range: 400Ω / 4kΩ / 40kΩ / 400kΩ / 4MΩ / 40MΩ
Jaw Opening Capacity: 42 mm

Overview

The FA370 Digital AC/DC Clamp Meter is a professional auto-range measuring device with 3999 counts, designed for reliable electrical testing. It supports measurement of DC/AC voltage, DC/AC current, resistance, capacitance, temperature, frequency, duty cycle, as well as diode and continuity tests, making it a versatile tool for engineers and technicians.

Equipped with a clear LCD display and backlight, it ensures easy data reading in different environments. The built-in low battery indicator alerts users before power runs out, while its advanced protection system automatically safeguards the meter from damage when exposed to excessive voltage or current.

Portable, durable, and accurate, the FA370 clamp meter is an ideal choice for industrial maintenance, electrical troubleshooting, and field applications.

Type	FA280	FA370	FA480
DC Voltage	600mV/6.6V/66V/600V	0.4V/4V/40V/400V/	6.6V/66V/660V/1000V
Accuracy	±0.8%+3	1000V (±0.7%+1)	±0.8%+3
AC Voltage	600mV/6.6V/66V/600V	4V/40V/400V/750V	6.6V/66V/660V/750V
Accuracy	±0.8%+3	±0.7%+1	±1.2%+5
DC Current	66A/600A	400A/1000A	660A/2000A
Accuracy	±3.0%+10	±3.0%+3	±2.5%+5
AC Current	66A/600A	400A/1000A	660A/2000A
Accuracy	±3.0%+10	±3.0%+3	±2.5%+5
Frequency	10kHz	40Hz/400Hz/4kHz/40kHz/100kHz	66Hz/660Hz/6.6kHz/66kHz/660kHz/6.6MHz/20MHz
Accuracy	±1.5%+5	±2%+1	±0.1%+3
Resistance	660Ω/6.6kΩ/66kΩ/660kΩ/6.6mΩ/66mΩ	400Ω/4kΩ/40kΩ/400kΩ/4mΩ/40mΩ	660Ω/6.6kΩ/66kΩ/6.6mΩ/66mΩ
Jaw Capability	26mm	42mm	63mm
Power	1.5V(AAA)×3	6F22, 9V	6F22, 9V
Dimension	280×78×35mm	250×99×43mm	298×100×48mm
